Cub Cadet XT2 GX 54 D Garden Tractor

Cub Cadet XT2 GX54 D Garden Tractor (“King of the Cadets”)

The Cub Cadet XT2 GX54 D is a high-performance garden tractor designed for homeowners who need more than a standard riding mower. With a powerful 25 HP Kohler engine and a 54-inch fabricated cutting deck, it delivers strong cutting performance across large lawns and challenging terrain.

The addition of a rear differential lock gives it enhanced traction in wet, uneven, or sloped conditions, while the Tuff Torq® K62 hydrostatic transmission ensures smooth and responsive control. Its FastAttach™ system allows quick connection of compatible attachments, making it highly versatile for year-round yard work.

Built with a reinforced steel frame, cast iron components, and a comfort-focused operator station, the XT2 GX54 D is engineered for durability, strength, and long-term reliability.

Heavy-Duty Garden Tractor Built for Tough Terrain

The Cub Cadet XT2 GX54 D is a premium garden tractor designed for power, traction, and durability across large and demanding yards. Equipped with a 25 HP Kohler® engine and a 54-inch fabricated AeroForce™ cutting deck, it delivers strong cutting performance and consistent results across uneven terrain and up to several acres of mowing.

With features like rear differential lock, hydrostatic transmission, and FastAttach™ compatibility, this model is built for homeowners who need tractor-level strength, towing capability, and attachment versatility—not just mowing performance.

Key Features

• Powerful 25 HP Kohler® 7000 Series Pro Performance engine (726cc)
• 54-inch fabricated AeroForce™ 3-blade cutting deck
• FastAttach™ system for quick, tool-free attachment changes
• Rear differential lock for improved traction on difficult terrain
• Tuff Torq® K62 upgraded hydrostatic transmission
• Cruise control for consistent mowing speed
• Heavy-duty brush guard front bumper included
• Dual LED headlights for improved visibility
• Foot-pedal hydrostatic drive control
• Electric PTO blade engagement for smooth operation
• 4 anti-scalp deck wheels for improved cut quality on uneven ground
• Armrest-equipped high-back seat for operator comfort
• Rear tow hitch included for attachments and utility use
• Heavy-duty 11-gauge fabricated steel deck construction

Engine Specifications

• Engine Brand: Kohler®
• Engine Model: 7000 Pro Performance KT740
• Engine Type: V-Twin OHV
• Engine Displacement: 726cc
• Horsepower: 25 HP
• Fuel Tank Capacity: 3.0 gallons (11.36 L)
• Fuel System: Carbureted
• Oil System: Fully pressurized with oil filter
• Oil Capacity: 2.1 quarts (2 L)
• Starting System: Electric key start
• Charging System: 15 Amp regulated
• Battery: 12V AGM (230 CCA)

Cutting Deck

• Cutting Width: 54 inches
• Deck Type: Fabricated AeroForce™
• Deck Material: 11-gauge steel
• Blade System: 3 blades
• Cutting Height Range: 1″ – 4″
• Deck Positions: 12
• Deck Lift: Manual
• Deck Engagement: Electric PTO
• Anti-Scalp Wheels: 4 gauge wheels
• Deck Wash System: Included
• Mulch Kit: Available separately

Drive System

• Transmission: Tuff Torq® K62 hydrostatic
• Drive Type: Foot-pedal controlled
• Forward Speed: 5.5 MPH (8.6 km/h)
• Reverse Speed: 3 MPH (4.8 km/h)
• Differential Lock: Rear locking differential
• Transmission Housing: Cast aluminum
• Engine-to-Transmission: Heavy-duty belt drive

Chassis & Construction

• Frame: Robotically welded steel frame
• Front Axle: Cast iron pivot bar
• Corrosion Protection: Yes
• Rear Hitch: Standard
• Bumper: Heavy-duty brush guard
• Turning Radius: 16 inches
• Rear Axle: 1-inch heavy-duty axle

Comfort & Controls

• Seat Type: 15″ high-back seat with armrests
• Seat Adjustment: Lever adjustable
• Floor Mat: Rubber
• Cruise Control: Yes
• Brakes: Disc brakes
• Cup Holder: Included
• Operator Presence System: Yes
• Headlights: Dual LED

Wheels & Tires

• Front Tires: 16″ × 6.5″ – 8″
• Rear Tires: 22″ × 9.5″ – 12″
• Tire Type: Turf Saver
• Bearings: Ball bearing wheels

Dimensions & Warranty

• Series: XT2 Enduro Series
• Frame Warranty: 5-year limited
• Deck Shell Warranty: Lifetime limited
• Front Axle Warranty: 5-year unlimited hours
• Standard Warranty: 3-year unlimited hours (powertrain included)
